DESIGNATION STRIPS
236
JACK PANELS
PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
DESIGNATION STRIPS (continued)
SINGLE HEIGHT DESIGNATION STRIPS
Part No.
TT501
Description
Kits (single height) includes:
1-mounting strip (8.375" long)
For Panels
1600, 1700
(Alternate
Part No.
DS301
Description
Kit (single height) includes:
1-mounting strip (17" long)
For Panels
1400301,
2600301
1-cover
1-marking strip sheet
(5 strips per sheet)
4-mounting screws
spacing)
1-cover
1-marking strip sheet
(5 strips per sheet)
4-mounting screws
TT502
Marking Strip sheet (used with
–
DS302
Cover (used with Kit DS301)
–
Kit TT501 & TT521)
DS303
Marking strip sheet (used with
TT503
TT504
Cover (used with Kit
TT501 and TT504)
Kits (single height) includes:
–
A1600, C1600
DS306
Kit DS301 and DS316).
Marking strip sheet (used with
Kit DS307 and DS308).
–
–
TT519
TT520
TT521
1-mounting strip (8.375" long)
1-cover
1-marking strip sheet
(5 strips per sheet)
4-mounting screws
Kit (single height) includes:
2-covers (9.61" long)
1- marking strip sheet
(5 strips per sheet)
Marking strip sheet (used with
Kit TT519)
Kit (single height) includes:
2-covers (8.25" long)
1- marking strip sheet
(5 strips per sheet)
(Continuous
spacing)
TT52, TT54
TT56, TT58
TT60, TT62
(23" Panels)
–
TT51, TT53
TT55, TT57
TT59, TT61,
Connectorized
Jackfields
(2-, 4- and 6 wire)
DS307
DS308
DS316
DS317
DS318
Kit (single height) includes:
2-covers (16.5" long)
1-marking strip sheet
(5 strips per sheet)
Kit (single height) includes:
2-covers (19.5" long)
1-marking strip sheet
(5 strips per sheet)
Kit (single height) includes:
2-covers (16.25" long)
1- marking strip sheet
(5 strips per sheet)
Marking strip sheet (used with
Kit DS318).
Kit (single height) includes:
2-covers (20" long)
1- marking strip sheet
JP012000,
JP032000,
JP052000
JP022000,
JP042000,
JP062000
JP072000
JP092000,
JP112000
–
JP082000
JP102000,
JP122000
(5 strips per sheet)
KWIK-CHANGE ? DESIGNATION STRIPS
(DOUBLE HEIGHT)
Double height strips allow larger legends. Can be factory
installed on Series 1600, B1600, 1700 and B1700 panels, or
may be ordered separately for customer installation.
? Series 1600/B1600: Four strips can be mounted, two
above each row of jack openings.
? Series 1700: Two strips can be mounted, two above or
two below (special order) the double row of jack openings.
? Series B1700: Two strips can be mounted (side-by-side)
above top row of jacks.
NOTE: When TT516 kits are mounted above top row of jacks on
Series 1600, B1600 and B1700, strips will overhang top edge
of panel by .156 inches For most applications, the strips help
seal the normal opening between adjacent panels. Series
B1700 panel mounting screws may have to be loosened to
facilitate removal of the panel above it in this type of installation.
SPECIFICATIONS
Mounting Strip: Black thermoplastic UL 94V-0.
Cover: Clear plastic.
Single Height Kwik-Change ?
Designation Strip, TT501
Double Height Kwik-
Change Designation
Strip, TT516
Series B1600
Series 1700
Marking Strip: Matte finish white plastic.
Mounting Screws: Copper alloy, plated.
ORDERING
1. Order by part number from table.
2. To order double height strips installed on panels,
contact Switchcraft.
Series B1700
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
